Bulkwing Chip Van

High Volume Belly Chip Van

Other benefits

  • Reinforced galvanized rear sill with integrated push blocks
  • 5 1/2" high open top aluminum extrusion top rail
  • Tarp supports factory installed for future roll tarp installation
  • Raised aluminum plate for electrical connectors on front wall for easy access

Optional features

Interior Liners

Option for aluminum skin including front wall or Kemlite LTR composite material

Rear End

Various door configurations, single, double, with wire mesh, with blower door

Cat Walk

Aluminum 18" or 24" wide on front wall with ladder


Coupler Height
King Pin
14" or 18"
Drop Height
35 1/2"
Sub Structure
Coupler Plate
5/16" thick, reinforced, 100 000 psi steel
Front Wall
Front Wall
6 Post Design, Pre-painted aluminum with double sheeting aluminum corners, unpolished on the outside and aluminum plate inside
Interior Liner
1/2" plywood with silicone sealed joints
One ladder made of aluminum, road side front wall
Side wall
Side Panels
.049" Prepainted White Aluminum Panels
Aluminum 45mm deep on 16" c/c full length
4 openings 11" x 19" on each side wall with perforated aluminum plate
Rear End
Door Frame
Galvanized (G164)
Rear Header
Steel formed 4"x4" x 3/16"
Single dump style, aluminum with door latch on door sill manually operated with a road side handle
Galvanized CMVSS & DOT approved with 4" x 4" roll formed tube cross bar with solid steel push bars
Open type
Roof Bows
3 galvanized steel, without offset and hinges
Tarp Support
1/4" aluminum plate each of the unit for roll type tarp
Main System
Grote Ultra Blue LED sealed lights & wiring harness system meets Transport Canada and DOT requirements
Back-up Lights
2 sealed beam spot lights in rubber grommet in rear sill
Landing Gear
Landing Gear
Holland 2 Speed
Galvanized and reinforced
Dummy Legs
Skids made of aluminum extrusion 4" x 1 1/4"
Fixed 1/4" thick, 80 000psi steel, C-shaped with plug welded connections
Hendrickson HT or Intraax air ride
ABS System
Wabco ABS 2S-1M
Air System
Fixed at front
Accessories & Finishing
Conspicuity tape complies with DOT and CMVSS standards
